TSURUMI Nk2-15 Manual electric 2HP submersible pump 3 in 220V, heavy duty, high head pumps capable of handling abrasive materials with minimal wear semi vortex impeller and synthetic rubber wear plates for maximum durability and maintaining pump performance. Dual Inside Mechanical Seal With SiC faces provides longer operational life. Oil Lifter provides lubrication of the seal faces. (Patent) V-Ring Seal design protects mechanical seal from abrasive particles.
Feature Bullets
- Terminal board for voltage reconnect allows for change from 110V to 220V
- Semi Vortex Impeller and Synthetic Rubber Wear Plates for maximum durability and maintaining pump performance
- Dual Inside Mechanical Seal with SiC faces provides longer operational life
- Oil lifter provides lubrication of the seal faces. (patent
- V-Ring Seal design protects mechanical seal from abrasive particles. (Optional Accessories)
- TS-304 Float switch for automatic operation (110V only)
- TS-303 Float switch for automatic operation (220V only)
- Sand kit to suspend solids and prevent clogging
Specifications:
Type: Manual
Voltage Rating: 110 V
Amperage Rating: 23 A
Frequency: 60 Hz
HP Rating: 2 hp
Speed Rating: 3440 rpm
Flow Rate: 96 gpm
Phase: 1
Discharge Size: 3 in
Cord Size: 32 ft
Maximum Feet of Head: 69 ft
Material: Aluminum
Dimensions: 9-7/16 in Diameter x 24-1/2 Height
Warranty: 2 Years
Documents
Dimensional Drawing
Documents
Specification Sheet
